    HBXG T140-1 Crawler Bullzoder Equipped with Weichai Engine and Steering clutch In 140 Horsepower

    Ask Lasest Price
    Brand Name : HBXG
    Model Number : T140-1
    Certification : ISO/FMRC/CCC
    Price : NEGOTIATION
    Payment Terms : L/C, T/T
    Supply Ability : 30 units per month
    Delivery Time : in 30 working days
    • Product Details
    • Company Profile

    HBXG T140-1 Crawler Bullzoder Equipped with Weichai Engine and Steering clutch In 140 Horsepower

    HBXG T140-1 Crawler Bullzoder Equipped with Weichai Engine and Steering clutch In 140 Horsepower


    SPECIFICATION:


    DozerTilt/AngleUndercarriage system
    Operating Weight(kg) with riper16200/16300Type
    Ground pressure(kpa)61.8/62.2Swing type sprayed beam
    Track gauge (mm)1880/1880Suspended structure of equalizer bar
    Gradient30/25
    Min.Ground clearance (mm)353/353

    N of track rollers

    N of carrier rollers

    6 for each side

    2 for each side

    Dozing capacity m34.5/4.0Pitch (mm)203
    Blade width (mm)3297/3762Width of shoe (mm)500
    Max digging depth (mm)400/400GearsForward
    Overall dimension

    5099*3297*3042

    5180*3762*3042

    Backward
    Engine TypeWeichaiImplement hydraulic system
    Rated reverlation1800Max.system pressure11.76 Mpa
    Engine power (kw)104Pump typeCBF-E100
    Rated fuel consumption(g/kw.h)<215System output (L/min)180
    Driving system
    Main clutchNormally opened, wet type, hydraulic booster control
    TransmissionNormally meshed helical gear drive, coupling sleeve shift and two lever operation, the transmission has fice forward and four backward speeds.
    Steering clutchMultiple-disc oil power metallurgy disc compressed by spring, hydraulic operated
    Steering brakeBrake is oil two direction floating band brake operated by mechanical foot pedal
    Final driveThe final drive are double reduction with spur gear and segment sprocket, which a sealed by duo-cone seal

    Application:

    It is widely used in road building, hydro-electric construction, field modification, port and mine development and other construction.
