    LG938 Front End Loader With Weichai Engine And 3000kg Rated Loading Capacity For Mining Site Using

    Ask Lasest Price
    Brand Name : SINOMTP
    Model Number : LG938
    Certification : ISO/CCC/BV
    Price : negotiation
    Supply Ability : 100 units per month
    Delivery Time : 35 days after payment
    • Product Details
    • Company Profile

    LG938 Front End Loader With Weichai Engine And 3000kg Rated Loading Capacity For Mining Site Using

    LG938 front end wheel loader with Weichai engine and 3000kg rated loading capacity for mining site using


    SPECIFICATION:


    Performance1rated loading3000kg
    2overall weight9800kg
    3rated bucket capacity1.8m3
    4maximum tractive force97KN
    5maximum breakout force127KN
    6maximum grade ability30℃
    7maximum dump height3100
    8maximum dump reach1006mm
    9overall dimension (L×W×H)6890×2430×3070mm
    10minimum turning radius5097mm
    Engine11modelDeutz WP6G125E22
    12typelnline water cooled, four stroke
    13No. of cylinder-bore/stroke6—108×125mm
    14rated power92kw
    15maximum torque500N.m
    16min fuel-consume ratio

    ≤210g/kw.h

    Drive axles21main reducing modeBevel gear grade lreduction
    22decelerating modeBevel gear grade lreduction
    23wheel base (mm)2660mm
    24wheel tread1800mm
    25ground clearance400mm

    LG938 Front End Loader With Weichai Engine And 3000kg Rated Loading Capacity For Mining Site UsingLG938 Front End Loader With Weichai Engine And 3000kg Rated Loading Capacity For Mining Site Using
